Model Number:N7-E46 - Pro
May 17, 2012 How To Use Navigation System in BMW 3 Series with BMW iDrive. Michael from Checkered Flag BMW demonstrates the features and functions of the navigation system in BMW models using BMW iDrive.
BMW series 7' Touch Screen LCD Multimedia Navigation System
FOR BMW 3 Series E46 1998-2006
High-quality 7'/16:9 LCD display with capacitive touchscreen (1024 x 600 resolution)
CANBUS integration
FM RDS TMC tuner with DSP noise masking and 15 preset stations
Integrate with Sound DSP processor with EQ, time correction and 4V pre-out
AV input/output
Disc player
Hands Free and Streaming Music
Multimedia player by USB connectivity and SD card reader
Reverse camera, TV, DAB+ ready
iLink Pro for carplay and android Auto ready
Made for iPhone iPod iPad
Navigation software with 3D landview and premium POI
Dynavin iLink Pro
Available on Dynavin N7 Pro platform , Dynavin iLink Pro is a smarter, safer way to use your iOS and Android Phone in the car. Dynavin iLink Pro takes the things you want to do with your iOS and Android Phone while driving and puts them right on your Dynavin display. You can get directions, make calls, send and receive messages, and listen to music, all in a way that allows you to stay focused on the road. Just connect your Smart phone and go.
Dual radio tuner
The Dynavin uses an FM phase diversity circuit, processing the signals of the dual antennas built into the vehicle. DSP algorithms create a noise and distortion free FM signal by merging both radio signals into a single new audio stream. Allowing for optimal radio reception even under the most challenging conditions.
SIriusXM Satellite Radio Ready
Upgrade Bmw Navigation System
Add the SiriusXM Connect Vehicle tuner (sold separately) to listen to your SiriusXM subscription anytime, anywhere.
IGO primo
Dynavin N7 Pro features a built-in navigation system with simple destination input, turn-by-turn voice prompts, and selectable route guidance - everything you need to reach your destination quickly and efficiently. Pre-loaded with rich points of interest, its database includes national parks, restaurants, petrol stations, and much more. Furthermore, Dynavin offer 30days FREE updating on the maps after the first use.
DSP sound
Dynavin N7 head units use high-resolution Burr Brown 24-Bit Digital to Analogue conversion allowing for clean, accurate, stunning sound reproduction.
Bmw X5 Navigation Instructions
Capacitive Anti-glare Touchscreen
View your Media and Navigation on a clear, hi resolution, display. A capacitive anti-glare touch panel gives you precise fingertip control and superior visibility in all lighting conditions.
More Detalis
Navigation 3D High-Definition navigation
SD card based navigation system
Premium P.O.I. bundle with over 6.5 million destinations
Realistic 3D rendering of terrains and landmarks, Tunnel-View, 3D Auto-Zoom for crossings and roundabouts, Real Junction View
Smart Route Planning, Calculation of Real-Time Route Alternatives, Parking Around Algorithm, Detour Hint function etc.
TMC receiver for free TMC data services*
30 Days Latest Map Guarantee
Bmw Navigation Manual Pdf
1. Steering wheel remote control integration
2. Optical Park System (OPS) integration
3. Onboard computer information integration
Tuner
Memory Presets: Preset Stations (FM:15 / MW: 15)
Memory: Auto Memory
RDS
RDS Functions: AF, TA, TP, PTY, NEWS, RADIO TEXT
Phone
Hands Free Calling
Phone Book Transfer
Phone Book Search: Alphabet Search
Favorite contacts
Wired Microphone Included
Redial Function
Call History Display
Adjusting the volume when receiving a call
Connection for iPod
Made for iPod/iPhone
USB Connection
Compatibility with iPod / iPhone / iPad with 30Pin or lightning connector
M.I.X. (Shuffle) Capability: Song, Albums, All
Music Control: Song Up/Down, Fast Forward/Backward, Repeat
Available Selections: Playlist, Artist, Album, Song, Podcast, Genre, Composer, Audiobook
Alphabet Search Function
Information Display: Album Art, Song (Title, Album)
Direct iPod/iPhone Control Function
Disc Player
DVD/CD Player
Disc Playback Type: DVD Video, DVD Audio (2ch mix down), CD, CD-R, CD-RW, DVD+-R/+-RW, DVD-VR
Compressed Media Playback: MPEG/ AVI /RM/ FLV/ ASF/ WMV/ MP4/ MKV/ OGM/ DivX/ MP3/ WMA/ AAC Playback
24bit-DAC
Sensor: Music Sensor Scan, Repeat
Playback Control: Play/Pause, Fast Forward/Backward
DVD Direct Menu Control
M.I.X. Mode: One (Folder) / All (Random Play) / Random (CD Only)
Bmw Owners Manual For Navigation
USB / SD Media Connection
USB Connection (USB Cable Included)
Cover Art Display
Music Playback: MP3/AAC/WMA Playback
USB Class: Mass Storage, Play from device
Available Selections: Playlist, Artist, Album, Song, Podcast, Genre, Composer, Audiobook
Alphabet Search Function
Information Display: Album Art, Song (Title, Album)
Sound Tuning
Bmw E46 Navigation System User Manual Template
Subwoofer Level Adjustment
Dyna-Bass level adjustment
Bass Level Adjustment
Treble Level Adjustment
Source Tone Memory
Time Correction Adjustment
Equalizer: 5-Band Parametric Equalizer Feature
General
Power Output: 4 x 50 W High Power Amplifier
High Grade Audiophile Design
SD Card: Video Playback
PreOut: 2 PreOuts (4V) and 1 AV Output
PreIn: 2 PreIn (Front / Rear) Ready
AUX-In: 1 AV Input
Steering Wheel Control Ready (Adapter Required)
Auto Dimmer
Power Antenna Output
Amplifier Remote Turn-On Output
Audio Interrupt
Camera Guide Line Adjustment
Dual Zone Control
Connection
Power & Speaker : ISO 16pin
Radio: Single Fakra / Dual Fakra
GPS: Fakra
Steering wheel control: Universal Analog steering wheel control
Max Power Output Ratings
Max Power Output: 4 x 50 W
FM Tuner
Tuning Range: 87.5 - 108.0 MHz
Mono Usable Sensitivity: 8.1 dBf (0.7 uV / 75 ohms)
Alternate Channel Selectivity: 80.0 dB
Signal-to-Noise (S/N) Ratio: 65.0 dB
Stereo Separation: 35.0 dB
Capture Ratio: 2.0 dB
Bmw E46 Navigation System Manual
MW Tuner
Bmw E46 Navigation System User Manual Format
Tuning Range: 531-1,602 kHz
Usable Sensitivity (IEC Standard): 25.1/28.0 (uV/dBf)
Navigation
Received Frequency: 1.57542 +-1.023MHz
Receiving Sensitivity: -130 dBm
Connection for USB
USB Requirements: USB 1.1/2.0
Max. Power Consumption: 1000 mA
USB Class: Mass Storage, Play from device
File System: FAT 32 / EXFAT
MP3 Decoding: MPEG-1/2 AUDIO Layer-3
WMA Decoding: Windows Media Audio
AAC Decoding: ACC-LC format '/m4a' file
Number of Channels: 2-Channel (Stereo)
Frequency Response: 5-20 kHz +-1 dB (Frequency Response may differ depending on the encoder software/bit rate)
Total Harmonic Distortion: 0.008% (at 1 kHz)
Dynamic Range: 95 dB (at 1 kHz)
Signal-to-Noise Ratio: 100 dB
Channel Separation: 85 dB (at 1 kHz)
Disc Player
Frequency Response: 20Hz~27Hz +-2 dB
Channel Separation (1kHz): 65 dB
Dynamic Range (1kHz): 85 dB
Total Harmonic Distortion (THD): 0.01% (at 1 kHz)
Wow & Flutter (%WRMS): B.M.L.
Audio Signal-to-Noise (S/N): 100 dB
Horizontal Resolution: 500 lines or greater
Video Output Level: 1 Vp-p (75 ohms)
Video Signal-to-Noise (S/N): DVD: 60 dB
Sound Tuning
Subwoofer Level Adjustment: 0 to 7
Bass Level Control Range: -7 to +7
Bass Center Frequency: 100Hz
Treble Level Control Range: -7 to +7
Treble Center Frequency: 10
Time Correction: 0-5 ms (0.1ms)
Graphic Equalizer: 7-Band (80, 250, 500, 1k, 4k, 8k, 16kHz), Adjustable Output Level -6 to +6dB
Map & Database
Online Update Method: visit www.naviextras.com
General
Power Requirement: 14.4 (11-16) V.DC
Screen Size: 7 inch / 6.2 inch Wide VGA Screen
Number of Picture Elements: 38400.00 pixels
Illumination System: LED
Pre Output Voltage (Before Clipping): 4 V
Operating Temperature (c): -10c - +70c
On-board 4GB HDD
